SR36-Gi2 Single Drum Roller-Road Rollers-Reliamachinery-RuiBeidi, Your Reliability in Construction Machinery

Road Rollers

SR36-Gi2 Single Drum Roller

ParameterValue
Total Weight36,000 kg
Engine Power276 kW
Compaction Width2,400 mm


Contact Us:xuefei2421@gmail.com

Here is the English version of the specifications in a table format based on the provided Chinese expert evaluation:

Expert Evaluation: The SR36-Gi2 is the latest fully upgraded large-tonnage fully hydraulic intelligent single-drum vibratory roller developed by Sinomach. It features dual modes of manual-assisted and unmanned operation. The unmanned mode is simple and easy to use, allowing one operator to control two machines working simultaneously. It also standardizes the compaction process. It is primarily used for compacting various materials in sub-bases, bases, and fill applications, making it ideal for water conservancy dams, high-grade highways, airports, and ports.

Parameter CategoryParameter NameSR36-Gi2
Performance ParametersOperating Mass (kg)36000

Centrifugal Force (kN)760/550

Vibration Frequency (Hz)26/31

Gradeability (%)50
EngineEngine ModelWeichai WP13

Rated Power / Rated Speed (kW/rpm)276 / 2100
DimensionsOverall Dimensions (L×W×H) (mm)7550 × 2930 × 3495
Travel PerformanceForward Speed (km/h)0-10

Reverse Speed (km/h)0-10
Chassis SystemWheelbase (mm)3600
Working DeviceCompaction Width (mm)2400
