The SR26-G is the latest fully upgraded, large-tonnage, fully hydraulic double-drive single-drum vibratory roller developed by Sinomach. It offers higher working efficiency, better economy, enhanced comfort, more convenient maintenance, smarter operation, and a more impressive appearance. It is suitable for compacting various non-cohesive soils, such as gravel, crushed stone, sand-gravel mixtures, and various concrete, making it ideal for large-scale foundation projects.
| Parameter Category | Parameter Name | SR26-G |
|---|---|---|
| Performance Parameters | Operating Mass (kg) | 26000 |
| Centrifugal Force (kN) | 500 / 360 | |
| Vibration Frequency (Hz) | 29 / 35 | |
| Ground Pressure (kPa) | - | |
| Gradeability (%) | 50 | |
| Engine | Engine Model | WP4.6N |
| Rated Power / Speed (kW/rpm) | 162 / 2200 | |
| Dimensions | Overall Dimensions (L×W×H) (mm) | 7000 × 2482 × 3370 |
| Travel Performance | Forward Speed (km/h) | 0-10 |
| Reverse Speed (km/h) | 0-10 | |
| Chassis System | Wheelbase (mm) | 3570 |
| Tank Capacity | Fuel Tank (L) | 330 |
| Working Device | Compaction Width (mm) | 2170 |
