| Parameter Name | Specification |
|---|---|
| Operating Weight | 36,000 kg |
| Engine Power | 276 kW |
| Compaction Width | 2,400 mm |
Contact Us:xuefei2421@gmail.com
The SR36-Gi2, developed by Sinotruk, is a next-generation large-tonnage fully hydraulic intelligent vibratory roller. It features dual operating modes—manual-assisted and unmanned driving—making it highly versatile and efficient. In unmanned mode, the roller is easy to operate, allowing one operator to control two units simultaneously. This ensures standardized compaction processes while significantly improving productivity.
Ideal for compacting sub-bases, base layers, and various fill materials, the SR36-Gi2 is the perfect solution for large-scale projects such as hydraulic dams, high-grade highways, airports, and ports.
| Parameter Name | Specification |
|---|---|
| Performance Parameters | |
| Operating Weight (kg) | 36,000 |
| Centrifugal Force (kN) | 760/550 |
| Vibration Frequency (Hz) | 26/31 |
| Gradeability (%) | 50 |
| Engine | |
| Engine Model | Weichai WP13 |
| Rated Power/Speed (kW/rpm) | 276/2100 |
| Dimensions | |
| Overall Dimensions (mm) | 7550×2930×3495 |
| Travel Performance | |
| Forward Speed (km/h) | 0-10 |
| Reverse Speed (km/h) | 0-10 |
| Chassis System | |
| Wheelbase (mm) | 3600 |
| Working Device | |
| Compaction Width (mm) | 2400 |
